Visualize GDD data wit Jupyter Notebook

Instructions

For dis lesson, you don gather GDD data wit IoT sensor. To get beta GDD data, you go need gather data for plenty days. To help you see temperature data well and calculate GDD, you fit use tools like Jupyter Notebooks to analyze di data.

Start by gathering data for some days. You go need make sure say your server code dey run anytime your IoT device dey run, either by adjusting your power management settings or running something like dis keep system active Python script.

Once you don get temperature data, you fit use di Jupyter Notebook wey dey dis repo to see am well and calculate GDD. Jupyter notebooks dey mix code and instructions inside blocks wey dem dey call cells, most times na Python code. You fit read di instructions, then run each block of code one by one. You fit also edit di code. For dis notebook example, you fit change di base temperature wey dem dey use calculate di GDD for your plant.

1. Create one folder wey you go call gdd-calculation

2. Download di gdd.ipynb file and put am inside di gdd-calculation folder.

3. Copy di temperature.csv file wey di MQTT server create.

4. Create new Python virtual environment inside di gdd-calculation folder.

5. Install some pip packages for Jupyter notebooks, plus libraries wey you go need to manage and plot di data:

   pip install --upgrade pip
   pip install pandas
   pip install matplotlib
   pip install jupyter


6. Run di notebook for Jupyter:

   jupyter notebook gdd.ipynb


   Jupyter go start and open di notebook for your browser. Follow di instructions wey dey di notebook to see di temperatures wey dem measure, and calculate di growing degree days.



Rubric

Criteria	Exemplary	Adequate	Needs Improvement
Capture data	Capture at least 2 complete days of data	Capture at least 1 complete day of data	Capture some data
Calculate GDD	Successfully run di notebook and calculate GDD	Successfully run di notebook	No fit run di notebook

---
